Molex
CONN RCPT 8POS 0.039 TIN SMD
949 Pcs New Original In Stock
8 Position Receptacle Connector 0.039" (1.00mm) Surface Mount Tin
Request Quote
(Ships tomorrow)
*Quantity
Minimum 1
Minimum 1
5.0 / 5.0
- (435 Ratings)
0523650891
Product Overview
2108781
DiGi Electronics Part Number
0523650891-DGManufacturer
Molex
0523650891
Description
CONN RCPT 8POS 0.039 TIN SMDInventory
949 Pcs New Original In Stock
8 Position Receptacle Connector 0.039" (1.00mm) Surface Mount Tin
Quantity
Minimum 1
Minimum 1
Purchase and inquiry
Warranty & Returns
How to Order
Shipping & Delivery
Quality Assurance
365 - Day Quality Guarantee - Every part fully backed.
90 - Day Refund or Exchange - Defective parts? No hassle.
Limited Stock, Order Now - Get reliable parts without worry.
Global Shipping & Secure Packaging
Worldwide Delivery in 3-5 Business Days
100% ESD Anti-Static Packaging
Real-Time Tracking for Every Order
Secure & Flexible Payment
Credit Card, VISA, MasterCard, PayPal, Western Union, Telegraphic Transfer(T/T) and more
All payments encrypted for security
0523650891 Technical Specifications
Category
Rectangular Connectors, Headers, Receptacles, Female Sockets
Packaging
Tape & Reel (TR)
Series
52365
Product Status
Obsolete
Connector Type
Receptacle
Contact Type
Forked
Style
Board to Board
Number of Positions
8
Number of Positions Loaded
All
Pitch - Mating
0.039" (1.00mm)
Number of Rows
2
Row Spacing - Mating
0.057" (1.45mm)
Mounting Type
Surface Mount
Termination
Solder
Fastening Type
Push-Pull
Contact Finish - Mating
Tin
Contact Finish Thickness - Mating
-
Insulation Color
-
Insulation Height
0.157" (4.00mm)
Contact Length - Post
-
Operating Temperature
-40°C ~ 105°C
Material Flammability Rating
UL94 V-0
Contact Finish - Post
Tin
Mated Stacking Heights
-
Ingress Protection
-
Features
Solder Retention
Current Rating (Amps)
0.5A
Voltage Rating
50V
Applications
-
Insulation Material
Polyamide (PA46), Nylon 4/6
Contact Shape
Square
Contact Material
Phosphor Bronze
Contact Finish Thickness - Post
-
Base Product Number
052365
Datasheet & Documents
HTML Datasheet
0523650891-DG
Environmental & Export Classification
RoHS Status
RoHS non-compliant
Moisture Sensitivity Level (MSL)
1 (Unlimited)
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8536.69.4040
Additional Information
Other Names
900-0523650891TR
52365-0891
052365-0891
52365-0891-C
052365-0891-C
52365-0820
523650891-C
0523650891-C
52365-0891-DG
523650891
Standard Package
1,000
