UAT56A05L05
Product Overview
10419710
DiGi Electronics Part Number
UAT56A05L05-DGManufacturer
YAGEO
UAT56A05L05
Description
TVS ESD, SOT-563, 5V, 15V, REELInventory
2294 Pcs New Original In Stock
15V Clamp 2A (8/20µs) Ipp Tvs Diode Surface Mount SOT-563
Quantity
Minimum 1
Minimum 1
Purchase and inquiry
Warranty & Returns
How to Order
Shipping & Delivery
Quality Assurance
365 - Day Quality Guarantee - Every part fully backed.
90 - Day Refund or Exchange - Defective parts? No hassle.
Limited Stock, Order Now - Get reliable parts without worry.
Global Shipping & Secure Packaging
Worldwide Delivery in 3-5 Business Days
100% ESD Anti-Static Packaging
Real-Time Tracking for Every Order
Secure & Flexible Payment
Credit Card, VISA, MasterCard, PayPal, Western Union, Telegraphic Transfer(T/T) and more
All payments encrypted for security
UAT56A05L05 Technical Specifications
Category
Transient Voltage Suppressors (TVS), TVS Diodes
Packaging
Tape & Reel (TR)
Series
UAT56A05L05
Product Status
Active
Type
Steering (Rail to Rail)
Unidirectional Channels
4
Voltage - Reverse Standoff (Typ)
5V (Max)
Voltage - Breakdown (Min)
6V
Voltage - Clamping (Max) @ Ipp
15V
Current - Peak Pulse (10/1000µs)
2A (8/20µs)
Power - Peak Pulse
-
Power Line Protection
Yes
Applications
Ethernet, USB
Capacitance @ Frequency
1pF @ 1MHz
Operating Temperature
-55°C ~ 150°C (TJ)
Mounting Type
Surface Mount
Package / Case
SOT-563, SOT-666
Supplier Device Package
SOT-563
Datasheet & Documents
HTML Datasheet
UAT56A05L05-DG
Environmental & Export Classification
Moisture Sensitivity Level (MSL)
1 (Unlimited)
ECCN
EAR99
HTSUS
8541.10.0080
Additional Information
Other Names
13-UAT56A05L05TR
Standard Package
3,000
Reviews
5.0/5.0-(Show up to 5 Ratings)
Dec 02, 2025
DiGi Electronics demonstrates a strong commitment to customer satisfaction through their support.
Dec 02, 2025
Efficiency in shipping and high-quality packaging set DiGi Electronics apart.
Dec 02, 2025
I highly recommend DiGi Electronics for their reliable, high-quality products and expert customer care.
Publish Evalution
Evalution Message
Please enter your review message.
Please post honest comments and do not post ilegal comments.
Frequently Asked Questions (FAQ)
What is the main function of the Yageo UAT56A05L05 TVS diode?
The UAT56A05L05 TVS diode is designed to protect electronic circuits from voltage transients and electrostatic discharge (ESD), ensuring device safety and reliability.
Is the UAT56A05L05 suitable for Ethernet and USB applications?
Yes, this TVS diode is specifically suitable for Ethernet and USB port protection, providing reliable surge and ESD suppression in these contexts.
What are the key electrical specifications of the UAT56A05L05 TVS diode?
This diode features a 5V reverse standoff voltage, a minimum breakdown voltage of 6V, a maximum clamping voltage of 15V at 2A peak pulse, and a capacitance of 1pF at 1MHz.
Is the UAT56A05L05 compatible with surface mount PCB designs?
Yes, it is a surface-mount device available in the SOT-563 package, suitable for compact PCB assemblies and automated manufacturing processes.
What are the operating temperature range and packaging details for this TVS diode?
The diode operates from -55°C to 150°C and is packaged in Tape & Reel for easy automated mounting, with a moisture sensitivity level of unlimited (MSL 1).
